دیتاشیت PTN78020WAH
مشخصات دیتاشیت
| نام دیتاشیت | PTN78020W,H Series |
|---|---|
| حجم فایل | 493.386 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 27 |
دانلود دیتاشیت PTN78020W,H Series |
PTN78020W,H Series Datasheet |
|---|
مشخصات
- Type: Non-Isolated PoL Module
- Efficiency: 94%
- Voltage - Output 2: -
- Mounting Type: Through Hole
- Package / Case: 7-DIP Module
- Series: PTN78020W
- Number of Outputs: 1
- Voltage - Input (Min): 7V
- Part Status: Active
- Base Part Number: PTN780
- Current - Output (Max): 6A
- Packaging: Tray
- Manufacturer: Texas Instruments
- Voltage - Output 3: -
- Features: UVLO
- Voltage - Output 1: 2.5 ~ 12.6V
- Size / Dimension: 1.50" L x 0.87" W x 0.35" H (38.1mm x 22.1mm x 8.9mm)
- Operating Temperature: -40°C ~ 85°C
- Voltage - Input (Max): 36V
- Applications: ITE (Commercial)
- detail: Non-Isolated PoL Module DC DC Converter 1 Output 2.5 ~ 12.6V 6A 7V - 36V Input
