LM158/258/358/2904 Datasheet 数据手册

LM158/258/358/2904 Datasheet

数据手册规格

数据手册名称 LM158/258/358/2904 Datasheet
文件大小 2133.177 千字节
文件类型 pdf
页数 40

下载数据手册 LM158/258/358/2904 Datasheet

下载数据手册

其他文档

LM158J 39 pages

技术规格

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Texas Instruments LM158H
  • -3db Bandwidth: -
  • Output Current: 40mA
  • Operating Temperature: -55°C~+125°C
  • Current - Input Bias(Ib): 40nA
  • Gain Bandwidth Product(GBP): 1MHz
  • Package: TO-99-8
  • Manufacturer: Texas Instruments
  • Voltage - Input Offset: 2mV
  • Current - Supply: 1mA
  • Mounting Type: Through Hole
  • Package / Case: TO-99-8 Metal Can
  • Amplifier Type: General Purpose
  • Series: -
  • Base Part Number: LM158
  • Part Status: Active
  • Gain Bandwidth Product: 1MHz
  • Current - Input Bias: 45nA
  • Voltage - Supply, Single/Dual (±): 3V ~ 32V, ±1.5V ~ 16V
  • Number of Circuits: 2
  • Packaging: Bulk
  • Output Type: -
  • Supplier Device Package: TO-99-8
  • Slew Rate: 0.5V/µs
  • detail: General Purpose Amplifier 2 Circuit TO-99-8
