دیتاشیت STM32L063R8T6
مشخصات دیتاشیت
| نام دیتاشیت | STM32L063C8, R8 Datasheet |
|---|---|
| حجم فایل | 1869.627 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 130 |
دانلود دیتاشیت STM32L063C8, R8 Datasheet |
STM32L063C8, R8 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: 64KB
- CPU Core: ARM-MSeries
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 8KB
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): 12bit
- Datasheet: STMicroelectronics STM32L063R8T6
- PWM (Bit): -
- LCD Module: Yes
- Real-Time Clock: -
- CPU Maximum Speed: 32MHz
- GPIO Ports Number: 51
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: DMA;LCD/LED Driver
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 64KB
- Universal Serial Bus: Yes
- communication protocol: -
- Operating Voltage Range: 1.65V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: LQFP-64(10x10)
- Manufacturer: STMicroelectronics
- Series: STM32L0
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M0+
- Core Size: 32-Bit
- Speed: 32MHz
- Connectivity: I²C, IrDA, SPI, UART/USART, USB
- Peripherals: Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
- Number of I/O: 51
- Program Memory Size: 64KB (64K x 8)
- EEPROM Size: 2K x 8
- Voltage - Supply (Vcc/Vdd): 1.65V ~ 3.6V
- Data Converters: A/D 16x12b; D/A 1x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 64-LQFP
- Supplier Device Package: 64-LQFP (10x10)
- Base Part Number: STM32L063
- detail: ARM® Cortex®-M0+ STM32L0 Microcontroller IC 32-Bit 32MHz 64KB (64K x 8) FLASH 64-LQFP (10x10)
