PTD08A010WAD دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
PTD08A010WAD
|
|
حجم فایل
|
103.453
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
15
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Power Modules
-
Datasheet:
Texas Instruments PTD08A010WAD
-
Package:
DIP-12
-
Manufacturer:
Texas Instruments
-
Type:
Non-Isolated PoL Module
-
Efficiency:
95%
-
Voltage - Output 2:
-
-
Mounting Type:
Through Hole
-
Package / Case:
12-DIP Module
-
Series:
Powertrain™
-
Number of Outputs:
1
-
Voltage - Input (Min):
4.75V
-
Part Status:
Active
-
Base Part Number:
PTD08A
-
Current - Output (Max):
10A
-
Packaging:
Tray
-
Voltage - Output 3:
-
-
Features:
-
-
Voltage - Output 1:
0.7 ~ 3.6V
-
Size / Dimension:
0.75" L x 0.62" W x 0.32" H (19.1mm x 15.7mm x 8.1mm)
-
Operating Temperature:
-40°C ~ 85°C
-
Voltage - Input (Max):
14V
-
Applications:
ITE (Commercial)
-
detail:
Non-Isolated PoL Module DC DC Converter 1 Output 0.7 ~ 3.6V 10A 4.75V - 14V Input
