STM32L4R5AGI6 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | STM32L4R5AGI6 |
|---|---|
| حجم فایل | 79.718 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 285 |
دانلود دیتاشیت STM32L4R5AGI6 |
دانلود دیتاشیت |
|---|
سایر مستندات
STM32F3, F4, L4 Series Prog Manual 262 pages
STM32L4R5xx, 7xx, 9xx Datasheet 307 pages
STM32L4Rzzz, 4Szzz Reference Manual 2301 pages
مشخصات فنی
- RoHS: true
- EEPROM: 1MB
- CPU Core: ARM Cortex-M4
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 640KB
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): 12bit
- Datasheet: STMicroelectronics STM32L4R5AGI6
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 120MHz
- GPIO Ports Number: 112
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 1MB
- Universal Serial Bus: Yes
- communication protocol: -
- Operating Voltage Range: 1.71V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: BGA-169
- Manufacturer: STMicroelectronics
- Series: STM32L4R
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M4
- Core Size: 32-Bit
- Speed: 120MHz
- Connectivity: CANbus, EBI/EMI, I²C, IrDA, LINbus, MMC/SD, SAI, SPI, UART/USART, USB OTG
- Peripherals: Brown-out Detect/Reset, DMA, POR, PWM, WDT
- Number of I/O: 112
- Program Memory Size: 1MB (1M x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 1.71V ~ 3.6V
- Data Converters: A/D 16x12b; D/A 2x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 169-UFBGA
- Supplier Device Package: 169-UFBGA (7x7)
- Base Part Number: STM32L4R5
- detail: ARM® Cortex®-M4 STM32L4R Microcontroller IC 32-Bit 120MHz 1MB (1M x 8) FLASH 169-UFBGA (7x7)
