TMS5701227CPGEQQ1 دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت TMS5701227CPGEQQ1	دانلود دیتاشیت

RoHS: true
CPU Core: ARM-RSeries
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
Watchdog: Yes
ADC (Bit): 12bit
Datasheet: Texas Instruments TMS5701227CPGEQQ1
CPU Maximum Speed: 160MHz
GPIO Ports Number: 58
Low-Voltage Detect: Yes
Direct Memory Access: Yes
Program Storage Size: 1.25MB
Operating Voltage Range: 1.14V~3.6V
Operating Temperature Range: -40°C~+125°C
Package: LQFP-144(20x20)
Manufacturer: Texas Instruments
Mounting Type: Surface Mount
RAM Size: 192K x 8
Connectivity: CANbus, EBI/EMI, Ethernet, FlexRay, I²C, LINbus, MibSPI, SPI, UCI, UART/USART
Packaging: Tray
Data Converters: A/D 24x12b
Number of I/O: 58
Core Size: 32-Bit Dual-Core
Core Processor: ARM® Cortex®-R4F
Supplier Device Package: 144-LQFP (20x20)
Operating Temperature: -40°C ~ 125°C (TA)
Part Status: Active
EEPROM Size: 64K x 8
Package / Case: 144-LQFP
Voltage - Supply (Vcc/Vdd): 1.14V ~ 3.6V
Program Memory Size: 1.25MB (1.25M x 8)
Base Part Number: TMS570
Speed: 160MHz
Series: Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R
Oscillator Type: External
Program Memory Type: FLASH
Peripherals: DMA, POR, PWM, WDT
detail: ARM® Cortex®-R4F Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R Microcontroller IC 32-Bit Dual-Core 160MHz 1.25MB (1.25M x 8) FLASH 144-LQFP (20x20)
