PTH12040WAD دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
PTH12040WAD
|
|
حجم فایل
|
76.572
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
27
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Power Modules
-
Datasheet:
Texas Instruments PTH12040WAD
-
Package:
DIP-20
-
Manufacturer:
Texas Instruments
-
Type:
Non-Isolated PoL Module
-
Efficiency:
96%
-
Voltage - Output 2:
-
-
Mounting Type:
Through Hole
-
Package / Case:
20-DIP Module
-
Series:
PTH12040
-
Number of Outputs:
1
-
Voltage - Input (Min):
8V
-
Part Status:
Active
-
Base Part Number:
PTH12
-
Current - Output (Max):
50A
-
Packaging:
Tray
-
Voltage - Output 3:
-
-
Features:
-
-
Voltage - Output 1:
0.8 ~ 5.5V
-
Size / Dimension:
2.05" L x 1.05" W x 0.36" H (52.1mm x 26.7mm x 9.1mm)
-
Operating Temperature:
-40°C ~ 85°C
-
Voltage - Input (Max):
14V
-
Applications:
ITE (Commercial)
-
detail:
Non-Isolated PoL Module DC DC Converter 1 Output 0.8 ~ 5.5V 50A 8V - 14V Input
