LM340K-5.0/NOPB Datasheet
Datasheet specifications
| Datasheet's name | LM340K-5.0/NOPB |
|---|---|
| File size | 90.264 KB |
| File type | |
| Number of pages | 23 |
Download Datasheet LM340K-5.0/NOPB |
Download Datasheet |
|---|
Other documentations
LM340(A), LM78xx Datasheet 34 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LM340K-5.0/NOPB
- Output Current: 1.5A
- Output Voltage: 5V
- Dropout Voltage: 2V@(1A)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 35V
- Operating Temperature: 0°C~+125°C
- Quiescent Current (Ground Current): 6mA
- Power Supply Rejection Ratio (PSRR): 70dB@(120Hz)
- Package: TO-3
- Manufacturer: Texas Instruments
- Series: -
- Voltage Dropout (Max): 2V @ 1A
- Package / Case: TO-204AA, TO-3
- Base Part Number: LM340
- Supplier Device Package: TO-3-2
- Current - Output: 1.5A
- Current - Quiescent (Iq): 6mA
- Part Status: Active
- Voltage - Input (Max): 35V
- Mounting Type: Through Hole
- Control Features: -
- Protection Features: Over Current, Short Circuit
- Voltage - Output (Min/Fixed): 5V
- PSRR: 70dB (120Hz)
- Voltage - Output (Max): -
- Packaging: Tray
- Output Configuration: Positive
- Number of Regulators: 1
- Output Type: Fixed
- detail: Linear Voltage Regulator IC 1 Output 1.5A TO-3-2
