X0405MF 1AA2 Datasheet

X0405MF 1AA2

Datasheet specifications

Datasheet's name X0405MF 1AA2
File size 56.891 KB
File type pdf
Number of pages 5

Download Datasheet X0405MF 1AA2

Download Datasheet

Other documentations

SCRs, Triacs, AC Switches and A.S.D.™ 26 pages

X04 Series 5 pages

Technical specifications

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/TRIACs
  • Datasheet: STMicroelectronics X0405MF 1AA2
  • Package: TO-202
  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Bulk
  • Part Status: Active
  • Voltage - Off State: 600V
  • Voltage - Gate Trigger (Vgt) (Max): 800mV
  • Current - Gate Trigger (Igt) (Max): 50µA
  • Voltage - On State (Vtm) (Max): 1.8V
  • Current - On State (It (AV)) (Max): 900mA
  • Current - On State (It (RMS)) (Max): 1.35A
  • Current - Hold (Ih) (Max): 5mA
  • Current - Off State (Max): 5µA
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 30A, 33A
  • SCR Type: Sensitive Gate
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Through Hole
  • Package / Case: TO-202 No Tab
  • Supplier Device Package: TO-202-3
  • Base Part Number: X0405
  • detail: SCR 600V 1.35A Sensitive Gate Through Hole TO-202-3
