دیتاشیت DAC7744EC

DAC7744

مشخصات دیتاشیت

نام دیتاشیت DAC7744
حجم فایل 1079.166 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت DAC7744

DAC7744 Datasheet

مشخصات

  • Part Status: Active
  • Voltage - Supply, Digital: 5V
  • Mounting Type: Surface Mount
  • Package / Case: 48-BSSOP (0.295", 7.50mm Width)
  • Settling Time: 11µs
  • Series: -
  • INL/DNL (LSB): ±4 (Max), ±3 (Max)
  • Differential Output: No
  • Operating Temperature: -40°C ~ 85°C
  • Voltage - Supply, Analog: ±14.25V ~ 15.75V
  • Reference Type: External
  • Data Interface: Parallel
  • Base Part Number: DAC7744
  • Number of Bits: 16
  • Packaging: Tube
  • Manufacturer: Texas Instruments
  • Output Type: Voltage - Buffered
  • Number of D/A Converters: 4
  • Supplier Device Package: 48-SSOP
  • Architecture: R-2R
  • detail: 16 Bit Digital to Analog Converter 4 48-SSOP
