SCRs, Triacs, AC Switches and A.S.D.™ Datasheet

SCRs, Triacs, AC Switches and A.S.D.™

Datasheet specifications

Datasheet's name SCRs, Triacs, AC Switches and A.S.D.™
File size 1580.585 KB
File type pdf
Number of pages 26

Download Datasheet SCRs, Triacs, AC Switches and A.S.D.™

Download Datasheet

Other documentations

BT(A,B)08, T8xx Datasheet 21 pages

Technical specifications

  • Manufacturer: STMicroelectronics
  • Series: Snubberless™
  • Packaging: Tube
  • Part Status: Active
  • Triac Type: Alternistor - Snubberless
  • Voltage - Off State: 600V
  • Current - On State (It (RMS)) (Max): 8A
  • Voltage - Gate Trigger (Vgt) (Max): 1.2V
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 80A, 84A
  • Current - Gate Trigger (Igt) (Max): 50mA
  • Current - Hold (Ih) (Max): 50mA
  • Configuration: Single
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
  • Supplier Device Package: D2PAK
  • Base Part Number: T850
  • detail: TRIAC Alternistor - Snubberless 600V 8A Surface Mount D2PAK
