ACST6 Datasheet

ACST6

Datasheet specifications

Datasheet's name ACST6
File size 440.905 KB
File type pdf
Number of pages 20

Download Datasheet ACST6

Download Datasheet

Other documentations

ACST Series Flyer 2 pages

Technical specifications

  • Manufacturer: STMicroelectronics
  • Series: ACS™/A.S.D®
  • Packaging: Tube
  • Part Status: Active
  • Triac Type: Logic - Sensitive Gate
  • Voltage - Off State: 800V
  • Current - On State (It (RMS)) (Max): 6A
  • Voltage - Gate Trigger (Vgt) (Max): 1V
  • Current - Non Rep. Surge 50, 60Hz (Itsm): 45A, 47A
  • Current - Gate Trigger (Igt) (Max): 10mA
  • Current - Hold (Ih) (Max): 25mA
  • Configuration: Single
  • Operating Temperature: -40°C ~ 125°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-262-3 Short Leads, I²Pak
  • Supplier Device Package: I2PAK
  • Base Part Number: ACST610
  • detail: TRIAC Logic - Sensitive Gate 800V 6A Through Hole I2PAK
