STPS30L120CFP دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
STPS30L120CFP
|
|
حجم فایل
|
45.398
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
14
|
مشخصات فنی
-
RoHS:
true
-
Category:
Diodes/Schottky Barrier Diodes (SBD)
-
Datasheet:
STMicroelectronics STPS30L120CFP
-
Diode Configuration:
Dual Common Cathode
-
Reverse Voltage (Vr):
120V
-
Forward Voltage (Vf@If):
1.08V@30A
-
Reverse Leakage Current (Ir):
200uA@120V
-
Average Rectified Current (Io):
15A
-
Package:
TO-220FP-AB
-
Manufacturer:
STMicroelectronics
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Type:
Schottky
-
Voltage - DC Reverse (Vr) (Max):
120V
-
Current - Average Rectified (Io) (per Diode):
15A
-
Voltage - Forward (Vf) (Max) @ If:
880mV @ 15A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
200µA @ 120V
-
Operating Temperature - Junction:
150°C (Max)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-3 Full Pack
-
Supplier Device Package:
TO-220FP
-
Base Part Number:
STPS30L120
-
detail:
Diode Array 1 Pair Common Cathode Schottky 120V 15A Through Hole TO-220-3 Full Pack
