دیتاشیت HSP054-4N10

مشخصات دیتاشیت

دانلود دیتاشیت HSP054-4N10	HSP054-4N10 Datasheet

Manufacturer: STMicroelectronics
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Type: Steering (Rail to Rail)
Unidirectional Channels: 4
Voltage - Reverse Standoff (Typ): 5V (Max)
Voltage - Breakdown (Min): -
Voltage - Clamping (Max) @ Ipp: 3.8V (Typ)
Current - Peak Pulse (10/1000µs): 3A (8/20µs)
Power - Peak Pulse: -
Power Line Protection: Yes
Applications: USB
Capacitance @ Frequency: -
Operating Temperature: -40°C ~ 150°C (TJ)
Mounting Type: Surface Mount
Package / Case: 10-XFDFN
Supplier Device Package: 10-uQFN (1.9x1)
detail: 3.8V (Typ) Clamp 3A (8/20µs) Ipp Tvs Diode Surface Mount 10-uQFN (1.9x1)
