دیتاشیت STQ3N45K3-AP

STQ3N45K3-AP Datasheet

مشخصات دیتاشیت

نام دیتاشیت STQ3N45K3-AP Datasheet
حجم فایل 892.555 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

دانلود دیتاشیت STQ3N45K3-AP Datasheet

STQ3N45K3-AP Datasheet Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: SuperMESH3™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 450V
  • Current - Continuous Drain (Id) @ 25°C: 600mA (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 3.8Ohm @ 500mA, 10V
  • Vgs(th) (Max) @ Id: 4.5V @ 50µA
  • Gate Charge (Qg) (Max) @ Vgs: 6nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 150pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 3W (Tc)
  • Operating Temperature: 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: TO-92-3
  • Package / Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
  • Base Part Number: STQ3
  • detail: N-Channel 450V 600mA (Tc) 3W (Tc) Through Hole TO-92-3
