SN74LVC1GU04DCKR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74LVC1GU04DCKR |
|---|---|
| حجم فایل | 88.631 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 43 |
دانلود دیتاشیت SN74LVC1GU04DCKR |
دانلود دیتاشیت |
|---|
سایر مستندات
SN74LVC1GU04 Datasheet 43 pages
مشخصات فنی
- RoHS: true
- Series: 74LVC
- Category: Logic ICs/Inverters
- Datasheet: Texas Instruments SN74LVC1GU04DCKR
- Input Type: -
- Sink Current: 32mA
- Source Current: 32mA
- Number of Inputs: 1
- Number of Circuits: 1
- Supply Current (Max): 10uA
- Low level range (VIL): 0.41V~1.38V
- Max Propagation Delay: 3.5ns@5V,50pF
- Operating Temperature: -40°C~+125°C
- High level range (VIH): 1.24V~4.13V
- Supply Voltage(Single): 1.65V~5.5V
- Package: SC-70-5
- Manufacturer: Texas Instruments
- Part Status: Active
- Max Propagation Delay @ V, Max CL: 3.5ns @ 5V, 50pF
- Package / Case: 5-TSSOP, SC-70-5, SOT-353
- Logic Level - Low: -
- Current - Output High, Low: 32mA, 32mA
- Base Part Number: SN74LVC1G
- Current - Quiescent (Max): 10µA
- Mounting Type: Surface Mount
- Voltage - Supply: 1.65V ~ 5.5V
- Packaging: Digi-Reel®
- Logic Type: Inverter
- Supplier Device Package: SC-70-5
- Features: -
- Logic Level - High: -
- detail: Inverter IC 1 Channel SC-70-5
