- دیتاشیت TMS570LS12x,11x Tech Ref Manual
TMS570LS12x,11x Tech Ref Manual دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TMS570LS12x,11x Tech Ref Manual |
|---|---|
| حجم فایل | 13474.221 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 2030 |
دانلود دیتاشیت TMS570LS12x,11x Tech Ref Manual |
دانلود دیتاشیت |
|---|
سایر مستندات
مشخصات فنی
- RoHS: true
- EEPROM: -
- CPU Core: ARM-RSeries
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): -
- Datasheet: Texas Instruments TMS5701227CZWTQQ1
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 180MHz
- GPIO Ports Number: 101
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: DMA;WDT
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 1.25MB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 1.14V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+125°C
- Secure Digital Input and Output: -
- Package: BGA-337
- Manufacturer: Texas Instruments
- Mounting Type: Surface Mount
- Connectivity: CANbus, EBI/EMI, Ethernet, FlexRay, I²C, LINbus, MibSPI, SPI, UCI, UART/USART
- Packaging: Tray
- Data Converters: A/D 24x12b
- Number of I/O: 101
- Core Size: 32-Bit Dual-Core
- Core Processor: ARM® Cortex®-R4F
- Supplier Device Package: 337-NFBGA (16x16)
- Operating Temperature: -40°C ~ 125°C (TA)
- Part Status: Active
- EEPROM Size: 64K x 8
- Package / Case: 337-LFBGA
- Voltage - Supply (Vcc/Vdd): 1.14V ~ 3.6V
- Program Memory Size: 1.25MB (1.25M x 8)
- Base Part Number: TMS570
- Speed: 180MHz
- Series: Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R
- Oscillator Type: External
- Peripherals: DMA, POR, PWM, WDT
- detail: ARM® Cortex®-R4F Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R Microcontroller IC 32-Bit Dual-Core 180MHz 1.25MB (1.25M x 8) FLASH 337-NFBGA (16x16)
