RM57L843BZWTT دیتاشیت

RM57L843BZWTT

مشخصات دیتاشیت

نام دیتاشیت RM57L843BZWTT
حجم فایل 95.934 کیلوبایت
نوع فایل pdf
تعداد صفحات 224

دانلود دیتاشیت RM57L843BZWTT

دانلود دیتاشیت

سایر مستندات

RM57L843 Datasheet 223 pages

RM57Lx Errata Rev B 50 pages

مشخصات فنی

  • CAN: -
  • I2C: -
  • I2S: -
  • SPI: -
  • RoHS: true
  • EEPROM: -
  • CPU Core: ARM-RSeries
  • Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
  • RAM Size: 512KB
  • Watchdog: Yes
  • ADC (Bit): 10bit;12bit
  • DAC (Bit): -
  • Datasheet: Texas Instruments RM57L843BZWTT
  • PWM (Bit): -
  • 8Bit Timer: -
  • UART/USART: -
  • 16Bit Timer: -
  • 32Bit Timer: -
  • Real-Time Clock: -
  • CPU Maximum Speed: 330MHz
  • GPIO Ports Number: 145
  • Low-Voltage Detect: Yes
  • CCP Capture/Compare: -
  • Internal Comparator: -
  • Internal Oscillator: -
  • Peripheral/Function: Ethernet protocol stack;LIN(Local Interconnect Network);WDT;DMA;PWM
  • Program Memory Type: FLASH
  • Direct Memory Access: Yes
  • Program Storage Size: 4MB
  • Universal Serial Bus: -
  • communication protocol: 以太网协议
  • Operating Voltage Range: 1.14V~3.6V
  • Infrared Data Association: -
  • Operating Temperature Range: -40°C~+105°C
  • Secure Digital Input and Output: -
  • Package: BGA-337
  • Manufacturer: Texas Instruments
  • Mounting Type: Surface Mount
  • Connectivity: CANbus, EBI/EMI, Ethernet, I²C, LINbus, MibSPI, SCI, UART/USART
  • Packaging: Tray
  • Data Converters: A/D 57x10/12b
  • Number of I/O: 145
  • Core Size: 16/32-Bit
  • Core Processor: ARM® Cortex®-R5F
  • Supplier Device Package: 337-NFBGA
  • Operating Temperature: -40°C ~ 105°C (TA)
  • Part Status: Active
  • EEPROM Size: 128K x 8
  • Package / Case: 337-LFBGA
  • Voltage - Supply (Vcc/Vdd): 1.14V ~ 3.6V
  • Program Memory Size: 4MB (4M x 8)
  • Base Part Number: RM57
  • Speed: 330MHz
  • Series: Hercules™ RM4 ARM® Cortex®-R5
  • Oscillator Type: External
  • Peripherals: DMA, POR, PWM, WDT
  • detail: ARM® Cortex®-R5F Hercules™ RM4 ARM® Cortex®-R5 Microcontroller IC 16/32-Bit 330MHz 4MB (4M x 8) FLASH 337-NFBGA
