TLV70333DBVR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TLV70333DBVR |
|---|---|
| حجم فایل | 79.53 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 27 |
دانلود دیتاشیت TLV70333DBVR |
دانلود دیتاشیت |
|---|
سایر مستندات
TLV703 Datasheet 24 pages
مشخصات فنی
- RoHS: true
- Noise: 48uVrms
- Feature: Thermal Protection;Overcurrent Protection;enable
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TLV70333DBVR
- Output Type: Fixed
- Output Current: 300mA
- Output Voltage: 3.3V
- Dropout Voltage: 375mV@300mA
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 5.5V
- Operating Temperature: -40°C~+125°C@(Tj)
- Quiescent Current (Ground Current): 55uA
- Power Supply Rejection Ratio (PSRR): 68dB@(1kHz)
- Package: SOT-23-5
- Manufacturer: Texas Instruments
- Mounting Type: Surface Mount
- Current - Supply (Max): 370µA
- Control Features: Current Limit
- Packaging: Cut Tape (CT)
- Voltage - Output (Max): -
- Voltage - Output (Min/Fixed): 3.3V
- Protection Features: Over Current
- Supplier Device Package: SOT-23-5
- Current - Quiescent (Iq): 55µA
- Part Status: Active
- Current - Output: 300mA
- Series: -
- Number of Regulators: 1
- PSRR: 68dB (1kHz)
- Base Part Number: TLV703
- Voltage Dropout (Max): 0.375V @ 300mA
- Package / Case: SC-74A, SOT-753
- Output Configuration: Positive
- Voltage - Input (Max): 5.5V
- detail: Linear Voltage Regulator IC 1 Output 300mA SOT-23-5
