- دیتاشیت TLV70025DCKR
TLV70025DCKR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TLV70025DCKR |
|---|---|
| حجم فایل | 86.726 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 37 |
دانلود دیتاشیت TLV70025DCKR |
دانلود دیتاشیت |
|---|
سایر مستندات
TLV700xx Datasheet 37 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TLV70025DCKR
- Output Current: 200mA
- Output Voltage: 2.5V
- Dropout Voltage: 0.25V@(200mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 5.5V
- Operating Temperature: -40°C~+125°C@(Tj)
- Quiescent Current (Ground Current): 55uA
- Power Supply Rejection Ratio (PSRR): 68dB@(1kHz)
- Package: SC-70-5
- Manufacturer: Texas Instruments
- Mounting Type: Surface Mount
- Current - Supply (Max): 270µA
- Control Features: Enable
- Packaging: Cut Tape (CT)
- Voltage - Output (Max): -
- Voltage - Output (Min/Fixed): 2.5V
- Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
- Output Type: Fixed
- Supplier Device Package: SC-70-5
- Current - Quiescent (Iq): 55µA
- Part Status: Active
- Current - Output: 200mA
- Series: -
- Number of Regulators: 1
- PSRR: 68dB (1kHz)
- Base Part Number: TLV700
- Voltage Dropout (Max): 0.25V @ 200mA
- Package / Case: 5-TSSOP, SC-70-5, SOT-353
- Output Configuration: Positive
- Voltage - Input (Max): 5.5V
- detail: Linear Voltage Regulator IC 1 Output 200mA SC-70-5
