دیتاشیت LM393DGKR

LM393DGKR

مشخصات دیتاشیت

نام دیتاشیت LM393DGKR
حجم فایل 101.888 کیلوبایت
نوع فایل pdf
تعداد صفحات 34

LM393DGKR

دانلود دیتاشیت

سایر مستندات

LM193,293,393(A), 2903(V) Datasheet 45 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Texas Instruments LM393DGKR
  • Output Type: 开集;轨到轨
  • Supply Current: 1mA
  • Supply Voltage: 2V~36V;1V~18V
  • Number of Elements: 2
  • Operating Temperature: 0°C~+70°C
  • Input Bias Current (Ib): 0.25uA
  • Input Offset Voltage (Vos): 5mV
  • Input Hysteresis Voltage (Vhys): -
  • Common Mode Rejection Ratio (CMRR): -
  • Package: VSSOP-8
  • Manufacturer: Texas Instruments
  • Current - Output (Typ): 20mA
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
  • Hysteresis: -
  • Base Part Number: LM393
  • Voltage - Input Offset (Max): 5mV @ 30V
  • Series: -
  • Current - Quiescent (Max): 2.5mA
  • Type: Differential
  • Voltage - Supply, Single/Dual (±): 2V ~ 36V, ±1V ~ 18V
  • CMRR, PSRR (Typ): -
  • Current - Input Bias (Max): 0.25µA @ 5V
  • Packaging: Cut Tape (CT)
  • Propagation Delay (Max): -
  • Supplier Device Package: 8-VSSOP
  • detail: Comparator Differential CMOS, MOS, Open-Drain, TTL 8-VSSOP
