دیتاشیت SN74AHC1GU04DCKR
مشخصات دیتاشیت
| نام دیتاشیت |
SN74AHC1GU04
|
| حجم فایل |
1195.66
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
24
|
مشخصات
-
RoHS:
true
-
Series:
74AHC
-
Category:
Logic ICs/Inverters
-
Datasheet:
Texas Instruments SN74AHC1GU04DCKR
-
Input Type:
-
-
Sink Current:
8mA
-
Source Current:
8mA
-
Number of Inputs:
1
-
Number of Circuits:
1
-
Supply Current (Max):
1uA
-
Low level range (VIL):
0.3V~1.1V
-
Max Propagation Delay:
7ns@5V,50pF
-
Operating Temperature:
-40°C~+85°C
-
High level range (VIH):
1.7V~4.4V
-
Supply Voltage(Single):
2V~5.5V
-
Package:
SOT-323-5
-
Manufacturer:
Texas Instruments
-
Part Status:
Active
-
Max Propagation Delay @ V, Max CL:
7ns @ 5V, 50pF
-
Package / Case:
5-TSSOP, SC-70-5, SOT-353
-
Logic Level - Low:
0.3V ~ 1.1V
-
Current - Output High, Low:
8mA, 8mA
-
Base Part Number:
SN74AHC1
-
Current - Quiescent (Max):
1µA
-
Mounting Type:
Surface Mount
-
Voltage - Supply:
2V ~ 5.5V
-
Packaging:
Cut Tape (CT)
-
Logic Type:
Inverter
-
Supplier Device Package:
SC-70-5
-
Features:
-
-
Logic Level - High:
1.7V ~ 4.4V
-
detail:
Inverter IC 1 Channel SC-70-5
