- دیتاشیت TPD1E05U06QDPYRQ1
دیتاشیت TPD1E05U06QDPYRQ1
مشخصات دیتاشیت
| نام دیتاشیت | TPD1E05U06QDPYRQ1 |
|---|---|
| حجم فایل | 79.507 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 25 |
TPD1E05U06QDPYRQ1 |
دانلود دیتاشیت |
|---|
سایر مستندات
TPDxE05U06-Q1 Datasheet 23 pages
مشخصات فنی
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/ESD Protection Devices
- Datasheet: Texas Instruments TPD1E05U06QDPYRQ1
- Clamping Voltage@Ipp: 14V
- Operating Temperature: -40°C~+125°C@(Ta)
- Breakdown Voltage (VBR): 6.4V
- Peak Pulse Power(Ppp)@8/20us: 30W
- Junction Capacitance(Cj)@1MHz: 0.42pF@1MHz
- Peak Pulse Current(Ipp)@8/20us: 2.5A@(8/20us)
- Reverse Stand-Off Voltage (Vrwm): 5.5V
- Package: X1-SON-2(0.6x1)
- Manufacturer: Texas Instruments
- Type: Steering (Rail to Rail)
- Part Status: Active
- Mounting Type: Surface Mount
- Package / Case: 0402 (1006 Metric)
- Capacitance @ Frequency: 0.42pF @ 1MHz
- Series: Automotive, AEC-Q101
- Power - Peak Pulse: 30W
- Voltage - Reverse Standoff (Typ): 5.5V (Max)
- Base Part Number: TPD1E
- Unidirectional Channels: 1
- Voltage - Breakdown (Min): 6.4V
- Current - Peak Pulse (10/1000µs): 2.5A (8/20µs)
- Power Line Protection: Yes
- Packaging: Cut Tape (CT)
- Supplier Device Package: 2-X1SON (1x.60)
- Voltage - Clamping (Max) @ Ipp: 14V (Typ)
- Applications: Automotive, HDMI, USB
- detail: 14V (Typ) Clamp 2.5A (8/20µs) Ipp Tvs Diode Surface Mount 2-X1SON (1x.60)
