- دیتاشیت SN74LVC1G3157DSFR
SN74LVC1G3157DSFR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74LVC1G3157DSFR |
|---|---|
| حجم فایل | 82.276 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 43 |
دانلود دیتاشیت SN74LVC1G3157DSFR |
دانلود دیتاشیت |
|---|
سایر مستندات
SN74LVC1G3157 Datasheet 45 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Texas Instruments SN74LVC1G3157DSFR
- Switch Circuit: -
- Package: X2-SON-6(1x1)
- Manufacturer: Texas Instruments
- Multiplexer/Demultiplexer Circuit: 2:1
- Mounting Type: Surface Mount
- Crosstalk: -54dB @ 10MHz
- Charge Injection: 7pC
- Current - Leakage (IS(off)) (Max): 1µA
- Voltage - Supply, Single (V+): 1.65V ~ 5.5V
- Switch Time (Ton, Toff) (Max): 5.7ns, 3.8ns
- -3db Bandwidth: 340MHz
- On-State Resistance (Max): 15Ohm
- Channel-to-Channel Matching (ΔRon): 100mOhm
- Supplier Device Package: 6-SON (1x1)
- Voltage - Supply, Dual (V±): -
- Operating Temperature: -40°C ~ 85°C (TA)
- Part Status: Active
- Package / Case: 6-XFDFN
- Base Part Number: SN74LVC1G
- Number of Circuits: 1
- Channel Capacitance (CS(off), CD(off)): 5.2pF
- Series: -
- Packaging: Cut Tape (CT)
- detail: 1 Circuit IC Switch 2:1 15Ohm 6-SON (1x1)
