SN74AUP1G14DRLR دیتاشیت

SN74AUP1G14DRLR

مشخصات دیتاشیت

نام دیتاشیت SN74AUP1G14DRLR
حجم فایل 105.819 کیلوبایت
نوع فایل pdf
تعداد صفحات 43

مشاهده دیتاشیت SN74AUP1G14DRLR

دانلود دیتاشیت

سایر مستندات

Logic Guide 20 pages

SN74AUP1G14 Datasheet 43 pages

مشخصات فنی

  • RoHS: true
  • Series: 74AUP
  • Category: Logic ICs/Inverters
  • Datasheet: Texas Instruments SN74AUP1G14DRLR
  • Input Type: Schmitt Trigger
  • Sink Current: 4mA
  • Source Current: 4mA
  • Number of channels: 1
  • Supply Current (Max): 500nA
  • Low level range (VIL): 0.1V~0.88V
  • Max Propagation Delay: 6.2ns@3.3V,30pF
  • Operating Temperature: 40°C~+85°C
  • High level range (VIH): 0.6V~2.29V
  • Supply Voltage(Single): 0.8V~3.6V
  • Package: SOT-5X3-5
  • Manufacturer: Texas Instruments
  • Part Status: Active
  • Max Propagation Delay @ V, Max CL: 6.2ns @ 3.3V, 30pF
  • Package / Case: SOT-553
  • Logic Level - Low: 0.1V ~ 0.88V
  • Current - Output High, Low: 4mA, 4mA
  • Base Part Number: SN74AUP
  • Current - Quiescent (Max): 500nA
  • Mounting Type: Surface Mount
  • Number of Inputs: 1
  • Voltage - Supply: 0.8V ~ 3.6V
  • Number of Circuits: 1
  • Packaging: Cut Tape (CT)
  • Logic Type: Inverter
  • Supplier Device Package: SOT-5
  • Features: Schmitt Trigger
  • Logic Level - High: 0.6V ~ 2.29V
  • detail: Inverter IC 1 Channel Schmitt Trigger SOT-5
