- دیتاشیت SN74LVC1G0832DBVR
دیتاشیت SN74LVC1G0832DBVR
مشخصات دیتاشیت
| نام دیتاشیت | SN74LVC1G0832DBVR |
|---|---|
| حجم فایل | 87.763 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
SN74LVC1G0832DBVR |
دانلود دیتاشیت |
|---|
سایر مستندات
Logic Guide 20 pages
Signal Switch Data Book 1267 pages
Digital Logic Data Book 794 pages
SN74LVC1G0832 Datasheet 23 pages
مشخصات فنی
- RoHS: true
- Series: 74LVC
- Category: Logic ICs/Gates
- Datasheet: Texas Instruments SN74LVC1G0832DBVR
- Sink Current: 32mA
- Source Current: 32mA
- Supply Voltage: 1.65V~5.5V
- Logic Gate Type: And;ORGate
- Number of Channels: 1
- Operating Temperature: -40°C~+85°C
- Package: SOT-23-6
- Manufacturer: Texas Instruments
- Part Status: Active
- Base Part Number: SN74LVC1G
- Package / Case: SOT-23-6
- Voltage - Supply: 1.65V ~ 5.5V
- Mounting Type: Surface Mount
- Number of Inputs: 3 Input (2, 1)
- Current - Output High, Low: 32mA, 32mA
- Number of Circuits: 1
- Packaging: Cut Tape (CT)
- Output Type: Single-Ended
- Logic Type: AND/OR Gate
- Supplier Device Package: SOT-23-6
- Schmitt Trigger Input: No
- detail: AND/OR Gate Configurable 1 Circuit 3 Input (2, 1) Input SOT-23-6
