LM317LILPR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | LM317LILPR |
|---|---|
| حجم فایل | 63.054 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 32 |
دانلود دیتاشیت LM317LILPR |
دانلود دیتاشیت |
|---|
سایر مستندات
LM317L Datasheet 33 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LM317LILPR
- Output Type: Adjustable
- Output Current: 100mA
- Output Voltage: 1.2V~32V
- Dropout Voltage: -
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 38V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 2.5mA
- Power Supply Rejection Ratio (PSRR): 80dB@(120Hz)
- Package: TO-92-3
- Manufacturer: Texas Instruments
- Part Status: Active
- Current - Output: 100mA
- Series: -
- Package / Case: TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
- Voltage - Output (Min/Fixed): 1.2V
- Control Features: -
- Number of Regulators: 1
- Mounting Type: Through Hole
- Voltage - Output (Max): 32V
- Base Part Number: LM317
- Protection Features: Over Current, Over Temperature, Short Circuit
- PSRR: 80dB ~ 65dB (120Hz)
- Voltage Dropout (Max): -
- Packaging: Cut Tape (CT)
- Output Configuration: Positive
- Supplier Device Package: TO-92-3
- Voltage - Input (Max): 38V
- detail: Linear Voltage Regulator IC 1 Output 100mA TO-92-3
