SN74AHC1G00QDCKRQ1 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74AHC1G00QDCKRQ1 |
|---|---|
| حجم فایل | 46.609 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت SN74AHC1G00QDCKRQ1 |
دانلود دیتاشیت |
|---|
سایر مستندات
SN74AHC1G00-Q1 11 pages
مشخصات فنی
- RoHS: true
- Series: 74AHC
- Category: Logic ICs/Gates
- Datasheet: Texas Instruments SN74AHC1G00QDCKRQ1
- Sink Current: 8mA
- Source Current: 8mA
- Supply Voltage: 2V~5.5V
- Logic Gate Type: NAND Gates
- Number of Channels: 1
- Low Level Range (VIL): 0.5V~1.65V
- Operating Temperature: -40°C~+125°C
- High Level Range (VIH): 1.5V~3.85V
- Propagation Delay Time: 7.5ns@5V,50pF
- Quiescent Current (Max): 1uA
- Package: SC-70-5
- Manufacturer: Texas Instruments
- Part Status: Active
- Max Propagation Delay @ V, Max CL: 7.5ns @ 5V, 50pF
- Package / Case: 5-TSSOP, SC-70-5, SOT-353
- Logic Level - Low: 0.5V ~ 1.65V
- Current - Output High, Low: 8mA, 8mA
- Base Part Number: SN74AHC1
- Current - Quiescent (Max): 1µA
- Mounting Type: Surface Mount
- Number of Inputs: 2
- Voltage - Supply: 2V ~ 5.5V
- Number of Circuits: 1
- Packaging: Digi-Reel®
- Logic Type: NAND Gate
- Supplier Device Package: SC-70-5
- Features: -
- Logic Level - High: 1.5V ~ 3.85V
- detail: NAND Gate IC 1 Channel SC-70-5
