- دیتاشیت SN74LVC1G14QDCKRQ1
SN74LVC1G14QDCKRQ1 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | SN74LVC1G14QDCKRQ1 |
|---|---|
| حجم فایل | 59.295 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 25 |
دانلود دیتاشیت SN74LVC1G14QDCKRQ1 |
دانلود دیتاشیت |
|---|
سایر مستندات
SN74LVC1G14-Q1 20 pages
مشخصات فنی
- RoHS: true
- Series: 74LVC
- Category: Logic ICs/Inverters
- Datasheet: Texas Instruments SN74LVC1G14QDCKRQ1
- Input Type: Schmitt Trigger
- Sink Current: 32mA
- Source Current: 32mA
- Number of Inputs: 1
- Number of Circuits: 1
- Supply Current (Max): 10uA
- Low level range (VIL): 0.39V~1.87V
- Max Propagation Delay: 13ns@1.8V,50pF
- Operating Temperature: -40°C~+125°C
- High level range (VIH): 1.16V~3.33V
- Supply Voltage(Single): 1.65V~5.5V
- Package: SC-70-5
- Manufacturer: Texas Instruments
- Mounting Type: Surface Mount
- Logic Level - Low: 0.39V ~ 1.87V
- Current - Quiescent (Max): 10µA
- Voltage - Supply: 1.65V ~ 5.5V
- Packaging: Digi-Reel®
- Package / Case: 5-TSSOP, SC-70-5, SOT-353
- Logic Level - High: 1.16V ~ 3.33V
- Part Status: Active
- Current - Output High, Low: 32mA, 32mA
- Features: Schmitt Trigger
- Base Part Number: SN74LVC1G
- Supplier Device Package: SC-70-5
- Logic Type: Inverter
- Max Propagation Delay @ V, Max CL: 6ns @ 5V, 50pF
- detail: Inverter IC 1 Channel Schmitt Trigger SC-70-5
