LM124,224,324,2902 Datasheet

LM124,224,324,2902

Datasheet specifications

Datasheet's name LM124,224,324,2902
File size 1851.711 KB
File type pdf
Number of pages 41

Download Datasheet LM124,224,324,2902

Download Datasheet

Other documentations

LM324AD 52 pages

LM324APWR 40 pages

Technical specifications

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Operational Amplifier
  • Datasheet: Texas Instruments LM324PWRG4
  • Package: TSSOP-14
  • Manufacturer: Texas Instruments
  • Current - Output / Channel: 40mA
  • Slew Rate: 0.5V/µs
  • Voltage - Input Offset: 3mV
  • Part Status: Active
  • Number of Circuits: 4
  • Operating Temperature: 0°C ~ 70°C
  • Packaging: Cut Tape (CT)
  • Supplier Device Package: 14-TSSOP
  • Package / Case: 14-TSSOP (0.173", 4.40mm Width)
  • Voltage - Supply, Single/Dual (±): 3V ~ 32V, ±1.5V ~ 16V
  • Series: -
  • Output Type: -
  • Base Part Number: LM324
  • Current - Supply: 1.4mA
  • Mounting Type: Surface Mount
  • Amplifier Type: General Purpose
  • Current - Input Bias: 20nA
  • Gain Bandwidth Product: 1.2MHz
  • detail: General Purpose Amplifier 4 Circuit 14-TSSOP
