CSD17381F4T دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
CSD17381F4T
|
|
حجم فایل
|
78.84
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
14
|
مشخصات فنی
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Texas Instruments CSD17381F4T
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
500mW
-
Total Gate Charge (Qg@Vgs):
1.35nC@4.5V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
195pF@15V
-
Continuous Drain Current (Id):
3.1A
-
Gate Threshold Voltage (Vgs(th)@Id):
1.1V@250uA
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
109mΩ@500mA,8V
-
Package:
PicoStar-3
-
Manufacturer:
Texas Instruments
-
Power Dissipation (Max):
500mW (Ta)
-
Drain to Source Voltage (Vdss):
30V
-
Rds On (Max) @ Id, Vgs:
109mOhm @ 500mA, 8V
-
Vgs (Max):
12V
-
FET Type:
N-Channel
-
Drive Voltage (Max Rds On, Min Rds On):
1.8V, 4.5V
-
Technology:
MOSFET (Metal Oxide)
-
Current - Continuous Drain (Id) @ 25°C:
3.1A (Ta)
-
FET Feature:
-
-
Input Capacitance (Ciss) (Max) @ Vds:
195pF @ 15V
-
Packaging:
Cut Tape (CT)
-
Package / Case:
3-XFDFN
-
Part Status:
Active
-
Series:
FemtoFET™
-
Vgs(th) (Max) @ Id:
1.1V @ 250µA
-
Gate Charge (Qg) (Max) @ Vgs:
1.35nC @ 4.5V
-
Supplier Device Package:
3-PICOSTAR
-
Mounting Type:
Surface Mount
-
Base Part Number:
CSD17381
-
detail:
N-Channel 30V 3.1A (Ta) 500mW (Ta) Surface Mount 3-PICOSTAR
