دیتاشیت LM317LCDR
مشخصات دیتاشیت
| نام دیتاشیت | LM317L Datasheet |
|---|---|
| حجم فایل | 1753.029 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 33 |
دانلود دیتاشیت LM317L Datasheet |
LM317L Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LM317LCDR
- Output Type: Adjustable
- Output Current: 100mA
- Output Voltage: 1.2V~32V
- Dropout Voltage: -
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 32V
- Operating Temperature: 0°C~+125°C
- Quiescent Current (Ground Current): 2.5mA
- Package: SOP-8
- Manufacturer: Texas Instruments
- Voltage - Input (Max): 38V
- Output Configuration: Positive
- Base Part Number: LM317
- Voltage - Output (Min/Fixed): 1.2V
- Protection Features: Over Current, Over Temperature, Short Circuit
- Series: -
- Packaging: Cut Tape (CT)
- PSRR: 80dB ~ 65dB (120Hz)
- Supplier Device Package: 8-SOIC
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Number of Regulators: 1
- Part Status: Active
- Control Features: -
- Voltage - Output (Max): 32V
- Mounting Type: Surface Mount
- Voltage Dropout (Max): -
- Current - Output: 100mA
- detail: Linear Voltage Regulator IC 1 Output 100mA 8-SOIC
