دیتاشیت TS5A3167DCKR
مشخصات دیتاشیت
| نام دیتاشیت |
TS5A3167
|
| حجم فایل |
1391.409
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
36
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Texas Instruments TS5A3167DCKR
-
Turn-on time:
7.5ns
-
Turn-off time:
11ns
-
Supply Voltage:
1.65V~5.5V
-
Switch Circuit:
SPST(SPST)-Normally closed
-
Number of Channels:
1
-
Operating Temperature:
-40°C~+85°C
-
On-State Resistance (Max):
0.9Ω
-
Package:
SC-70-5
-
Manufacturer:
Texas Instruments
-
Current - Leakage (IS(off)) (Max):
20nA
-
Voltage - Supply, Single (V+):
1.65V ~ 5.5V
-
Voltage - Supply, Dual (V±):
-
-
Number of Circuits:
1
-
Channel-to-Channel Matching (ΔRon):
-
-
Package / Case:
5-TSSOP, SC-70-5, SOT-353
-
Part Status:
Active
-
Supplier Device Package:
SC-70-5
-
Switch Time (Ton, Toff) (Max):
7.5ns, 11ns
-
Packaging:
Cut Tape (CT)
-
-3db Bandwidth:
150MHz
-
Mounting Type:
Surface Mount
-
Crosstalk:
-
-
Base Part Number:
TS5A316
-
Series:
-
-
Channel Capacitance (CS(off), CD(off)):
19pF, 18pF
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Charge Injection:
6pC
-
detail:
1 Circuit IC Switch 1:1 900mOhm SC-70-5
