دیتاشیت LP5907MFX-1.2/NOPB

LP5907 Datasheet

مشخصات دیتاشیت

نام دیتاشیت LP5907 Datasheet
حجم فایل 2224.203 کیلوبایت
نوع فایل pdf
تعداد صفحات 47

دانلود دیتاشیت LP5907 Datasheet

LP5907 Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments LP5907MFX-1.2/NOPB
  • Output Type: Fixed
  • Output Current: 250mA
  • Output Voltage: 1.2V
  • Dropout Voltage: 250mV@(250mA)
  • Output Polarity: Positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 5.5V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 25uA
  • Power Supply Rejection Ratio (PSRR): 90dB@(100Hz),60dB@(100kHz)
  • Package: SOT-23-5
  • Manufacturer: Texas Instruments
  • Current - Supply (Max): 425µA
  • Output Configuration: Positive
  • Package / Case: SC-74A, SOT-753
  • Packaging: Cut Tape (CT)
  • Protection Features: Over Temperature, Short Circuit
  • Number of Regulators: 1
  • Part Status: Active
  • Current - Quiescent (Iq): 25µA
  • Supplier Device Package: SOT-23-5
  • Voltage - Input (Max): 5.5V
  • Voltage - Output (Min/Fixed): 1.2V
  • Mounting Type: Surface Mount
  • PSRR: 90dB ~ 60dB (100Hz ~ 100kHz)
  • Base Part Number: LP5907
  • Series: -
  • Control Features: Enable
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 0.25V @ 250mA
  • Current - Output: 250mA
  • detail: Linear Voltage Regulator IC 1 Output 250mA SOT-23-5
