- دیتاشیت STM32F469xx Datasheet
STM32F469xx Datasheet دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | STM32F469xx Datasheet |
|---|---|
| حجم فایل | 3264.577 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 219 |
دانلود دیتاشیت STM32F469xx Datasheet |
دانلود دیتاشیت |
|---|
سایر مستندات
STM32F469BIT6 220 pages
مشخصات فنی
- RoHS: true
- EEPROM: -
- CPU Core: ARM Cortex-M4
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 384KB
- Watchdog: Yes
- ADC (Bit): 12bit
- DAC (Bit): 12bit
- Datasheet: STMicroelectronics STM32F469IIH6
- PWM (Bit): -
- LCD Module: Yes
- Real-Time Clock: -
- CPU Maximum Speed: 180MHz
- GPIO Ports Number: 114
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: DMA;LCD/LED Driver
- Program Memory Type: FLASH
- Direct Memory Access: Yes
- Program Storage Size: 2MB
- Universal Serial Bus: Yes
- communication protocol: -
- Operating Voltage Range: 1.7V~3.6V
- Infrared Data Association: Yes
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: Yes
- Package: UFBGA-201
- Manufacturer: STMicroelectronics
- Series: STM32F4
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM® Cortex®-M4
- Core Size: 32-Bit
- Speed: 180MHz
- Connectivity: CANbus, EBI/EMI, Ethernet, I²C, IrDA, LINbus, SAI, SDIO, SPI, UART/USART, USB, USB OTG
- Peripherals: Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT
- Number of I/O: 114
- Program Memory Size: 2MB (2M x 8)
- EEPROM Size: -
- Voltage - Supply (Vcc/Vdd): 1.7V ~ 3.6V
- Data Converters: A/D 24x12b; D/A 2x12b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 201-UFBGA
- Supplier Device Package: 176+25UFBGA (10x10)
- Base Part Number: STM32F469
- detail: ARM® Cortex®-M4 STM32F4 Microcontroller IC 32-Bit 180MHz 2MB (2M x 8) FLASH 176+25UFBGA (10x10)
