TL2843DR-8 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TL2843DR-8
|
|
حجم فایل
|
86.345
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
28
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Controllers
-
Function:
boost converterType;Buck-boost type
-
Topology:
Boost;Flyback;Forward
-
Datasheet:
Texas Instruments TL2843DR-8
-
Input Voltage:
7.6V~30V
-
Duty Cycle (Max):
97%
-
Number of Outputs:
1
-
Switching Frequency:
500kHz
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
SOIC-8
-
Manufacturer:
Texas Instruments
-
Voltage - Supply (Vcc/Vdd):
7.6V ~ 30V
-
Base Part Number:
TL284
-
Package / Case:
14-SOIC (0.154", 3.90mm Width)
-
Output Configuration:
Positive
-
Series:
-
-
Supplier Device Package:
14-SOIC
-
Frequency - Switching:
Up to 500kHz
-
Part Status:
Active
-
Mounting Type:
Surface Mount
-
Control Features:
Frequency Control
-
Clock Sync:
No
-
Serial Interfaces:
-
-
Packaging:
Cut Tape (CT)
-
Synchronous Rectifier:
No
-
Output Type:
Transistor Driver
-
Output Phases:
1
-
detail:
Boost, Flyback, Forward Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 14-SOIC
