TLV75733PDRVR دیتاشیت

TLV75733PDRVR

مشخصات دیتاشیت

نام دیتاشیت TLV75733PDRVR
حجم فایل 91.527 کیلوبایت
نوع فایل pdf
تعداد صفحات 36

دانلود دیتاشیت TLV75733PDRVR

دانلود دیتاشیت

سایر مستندات

TLV757xxP Datasheet 36 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments TLV75733PDRVR
  • Output Current: 1A
  • Output Voltage: 3.3V
  • Dropout Voltage: 0.475V@(1A)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 5.5V
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Package: WSON-6
  • Manufacturer: Texas Instruments
  • Current - Supply (Max): 40µA
  • Voltage - Input (Max): 5.5V
  • Output Configuration: Positive
  • Base Part Number: TLV757
  • Voltage - Output (Min/Fixed): 3.3V
  • Protection Features: Current Limit, Thermal Shutdown, UVLO
  • Series: -
  • Packaging: Cut Tape (CT)
  • PSRR: 52dB (1kHz ~ 1MHz)
  • Supplier Device Package: 6-WSON (2x2)
  • Package / Case: 6-WDFN Exposed Pad
  • Number of Regulators: 1
  • Part Status: Active
  • Output Type: Fixed
  • Control Features: Enable
  • Voltage - Output (Max): -
  • Mounting Type: Surface Mount
  • Voltage Dropout (Max): 0.475V @ 1A
  • Current - Output: 1A
  • detail: Linear Voltage Regulator IC 1 Output 1A 6-WSON (2x2)
