ESDA5-1BF4 Datasheet
Datasheet specifications
| Datasheet's name | ESDA5-1BF4 |
|---|---|
| File size | 232.451 KB |
| File type | |
| Number of pages | 10 |
Download Datasheet ESDA5-1BF4 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Bidirectional Channels: 1
- Voltage - Reverse Standoff (Typ): 5V
- Voltage - Breakdown (Min): 5.8V
- Voltage - Clamping (Max) @ Ipp: 11V
- Current - Peak Pulse (10/1000µs): 10A (8/20µs)
- Power - Peak Pulse: 110W
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: 45pF @ 1MHz
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 0201 (0603 Metric)
- Supplier Device Package: 0201
- Base Part Number: ESDA5
- detail: 11V Clamp 10A (8/20µs) Ipp Tvs Diode Surface Mount 0201
