DIP1524-01D3 Datasheet
Datasheet specifications
| Datasheet's name | DIP1524-01D3 |
|---|---|
| File size | 185.571 KB |
| File type | |
| Number of pages | 9 |
Download Datasheet DIP1524-01D3 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Type: Diplexer
- Frequency Bands (Low / High): 1573.42MHz ~ 1605.89MHz / 2.4GHz ~ 2.7GHz
- Low Band Attenuation (min / max dB): 20.00dB / -
- High Band Attenuation (min / max dB): 18.00dB / -
- Return Loss (Low Band / High Band): 10.0dB / 20.0dB
- Mounting Type: Surface Mount
- Package / Case: 4-UFBGA, FCBGA
- Base Part Number: DIP1524
- detail: RF Diplexor Diplexer 1573.42MHz ~ 1605.89MHz / 2.4GHz ~ 2.7GHz 4-UFBGA, FCBGA
