P6KE82CA دیتاشیت

P6KE82CA

مشخصات دیتاشیت

نام دیتاشیت P6KE82CA
حجم فایل 73.079 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت P6KE82CA

دانلود دیتاشیت

سایر مستندات

P6KE 9 pages

Littelfuse P6KE30A-B 6 pages

P6KE82CA 7 pages

مشخصات فنی

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: CREATEK P6KE82CA
  • Breakdown Voltage: 77.9V
  • Maximum Clamping Voltage: 113V
  • Reverse Leakage Current (Ir): 1uA
  • Reverse Stand-Off Voltage (Vrwm): 70.1V
  • Peak Pulse Current (Ipp)@10/1000us: 5.3A
  • Package: DO-15
  • Manufacturer: CREATEK
  • Bidirectional Channels: 1
  • Peak Pulse Power Dissipation (Ppp)@10/1000us: 600W
  • Series: P6KE, TRANSIL™
  • Packaging: Cut Tape (CT)
  • Part Status: Obsolete
  • Type: Zener
  • Voltage - Reverse Standoff (Typ): 70V
  • Voltage - Breakdown (Min): 77.9V
  • Voltage - Clamping (Max) @ Ipp: 146V
  • Current - Peak Pulse (10/1000µs): 27A (8/20µs)
  • Power - Peak Pulse: 600W
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: 275pF @ 1MHz
  • Operating Temperature: -
  • Mounting Type: Through Hole
  • Package / Case: DO-204AC, DO-15, Axial
  • Supplier Device Package: DO-15
  • Base Part Number: P6KE
  • detail: 146V Clamp 27A (8/20µs) Ipp Tvs Diode Through Hole DO-15
