دیتاشیت SMA6F18A

SMA6FxxA

مشخصات دیتاشیت

نام دیتاشیت SMA6FxxA
حجم فایل 685.254 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت SMA6FxxA

SMA6FxxA Datasheet

مشخصات

  • RoHS: true
  • Category: TVS/Fuse/Board Level Protection/TVS
  • Datasheet: STMicroelectronics SMA6F18A
  • Breakdown Voltage: 20V
  • Maximum Clamping Voltage: 29.2V
  • Reverse Leakage Current (Ir): 0.2uA
  • Reverse Stand-Off Voltage (Vrwm): 18V
  • Peak Pulse Current (Ipp)@10/1000μs: 21.5A
  • Peak Pulse Power Dissipation (Ppp)@10/1000μs: 600W
  • Package: SMA-flat
  • Manufacturer: STMicroelectronics
  • Series: SMA6F, TRANSIL™
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Zener
  • Unidirectional Channels: 1
  • Voltage - Reverse Standoff (Typ): 18V
  • Voltage - Breakdown (Min): 20V
  • Voltage - Clamping (Max) @ Ipp: 29.2V
  • Current - Peak Pulse (10/1000µs): 21.5A
  • Power - Peak Pulse: 600W
  • Power Line Protection: No
  • Applications: General Purpose
  • Capacitance @ Frequency: -
  • Operating Temperature: -55°C ~ 175°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: DO-221AC, SMA Flat Leads
  • Supplier Device Package: SMAflat
  • Base Part Number: SMA6F
  • detail: 29.2V Clamp 21.5A Ipp Tvs Diode Surface Mount SMAflat
