TPS22948DCKR دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت TPS22948DCKR	دانلود دیتاشیت

TPS22948 19 pages

RoHS: true
Category: Power Supply Chip/Power Distribution Switches
Datasheet: Texas Instruments TPS22948DCKR
Input Voltage: 2.5V~5.5V
Output Current: 130mA
Number of Outputs: 1
Resistor On-State: 300mΩ
Operating Temperature -: -40°C~+125°C
Package: SC-70-6
Manufacturer: Texas Instruments
Input Type: Non-Inverting
Output Configuration: -
Operating Temperature: -40°C ~ 125°C (TA)
Packaging: Cut Tape (CT)
Ratio - Input:Output: 1:1
Switch Type: General Purpose
Part Status: Active
Supplier Device Package: SC-70-6
Mounting Type: Surface Mount
Fault Protection: Current Limiting (Fixed), Over Temperature, Reverse Current
Rds On (Typ): 300mOhm
Current - Output (Max): 130mA
Package / Case: 6-TSSOP, SC-88, SOT-363
Series: -
Interface: -
Base Part Number: TPS229
Features: Auto Restart
Output Type: N/P-Channel
Voltage - Supply (Vcc/Vdd): Not Required
Voltage - Load: 2.5V ~ 5.5V
detail: Power Switch/Driver 1:1 N/P-Channel 130mA SC-70-6
