CSD17484F4T دیتاشیت

CSD17484F4T

مشخصات دیتاشیت

نام دیتاشیت CSD17484F4T
حجم فایل 77.578 کیلوبایت
نوع فایل pdf
تعداد صفحات 14

مشاهده دیتاشیت CSD17484F4T

دانلود دیتاشیت

سایر مستندات

CSD17484F4 Datasheet 14 pages

مشخصات فنی

  • RoHS: true
  • Category: Triode/MOS Tube/Transistor/MOSFETs
  • Datasheet: Texas Instruments CSD17484F4T
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Power Dissipation (Pd): 500mW
  • Total Gate Charge (Qg@Vgs): 0.2nC@8V
  • Drain Source Voltage (Vdss): 30V
  • Input Capacitance (Ciss@Vds): 195pF@15V
  • Continuous Drain Current (Id): 3A
  • Gate Threshold Voltage (Vgs(th)@Id): 1.1V@250uA
  • Drain Source On Resistance (RDS(on)@Vgs,Id): 121mΩ@500mA,8V
  • Package: PicoStar-3
  • Manufacturer: Texas Instruments
  • Power Dissipation (Max): 500mW (Ta)
  • Drain to Source Voltage (Vdss): 30V
  • Rds On (Max) @ Id, Vgs: 121mOhm @ 500mA, 8V
  • Vgs (Max): 12V
  • FET Type: N-Channel
  • Drive Voltage (Max Rds On, Min Rds On): 1.8V, 8V
  • Technology: MOSFET (Metal Oxide)
  • Current - Continuous Drain (Id) @ 25°C: 3A (Ta)
  • FET Feature: -
  • Input Capacitance (Ciss) (Max) @ Vds: 195pF @ 15V
  • Packaging: Cut Tape (CT)
  • Package / Case: 3-XFDFN
  • Part Status: Active
  • Series: FemtoFET™
  • Vgs(th) (Max) @ Id: 1.1V @ 250µA
  • Gate Charge (Qg) (Max) @ Vgs: 0.2nC @ 8V
  • Supplier Device Package: 3-PICOSTAR
  • Mounting Type: Surface Mount
  • Base Part Number: CSD17484
  • detail: N-Channel 30V 3A (Ta) 500mW (Ta) Surface Mount 3-PICOSTAR
