技术规格
- Manufacturer: STMicroelectronics
- Series: ESDA
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Bidirectional Channels: 1
- Voltage - Reverse Standoff (Typ): 6V
- Voltage - Breakdown (Min): 7V
- Voltage - Clamping (Max) @ Ipp: 16V (Typ)
- Current - Peak Pulse (10/1000µs): 8.6A (8/20µs)
- Power - Peak Pulse: 165W
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: 30pF @ 1MHz
- Operating Temperature: -40°C ~ 125°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 0201 (0603 Metric)
- Supplier Device Package: 0201
- Base Part Number: ESDALC8
- detail: 16V (Typ) Clamp 8.6A (8/20µs) Ipp Tvs Diode Surface Mount 0201
