BZW06-5V8(B)/376(B) 数据手册
其他文档
BZW06-15B 9 pages
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: STMicroelectronics BZW06-58BRL
- Breakdown Voltage: 64.6V
- Bidirectional Channels: 1
- Maximum Clamping Voltage: 121V
- Reverse Leakage Current (Ir): 0.2uA
- Reverse Stand-Off Voltage (Vrwm): 58.1V
- Peak Pulse Current (Ipp)@10/1000us: 33A@8/20us
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 600W
- Package: DO-15
- Manufacturer: STMicroelectronics
- Series: BZW06, TRANSIL™
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: Zener
- Voltage - Reverse Standoff (Typ): 58.1V
- Voltage - Breakdown (Min): 64.6V
- Voltage - Clamping (Max) @ Ipp: 121V
- Current - Peak Pulse (10/1000µs): 33A (8/20µs)
- Power - Peak Pulse: 600W
- Power Line Protection: No
- Applications: General Purpose
- Capacitance @ Frequency: 312.5pF @ 1MHz
- Operating Temperature: -
- Mounting Type: Through Hole
- Package / Case: DO-204AC, DO-15, Axial
- Supplier Device Package: DO-15
- Base Part Number: BZW06
- detail: 121V Clamp 33A (8/20µs) Ipp Tvs Diode Through Hole DO-15
