دیتاشیت HSP053-4M5

HSP053-4M5 Datasheet

مشخصات دیتاشیت

نام دیتاشیت HSP053-4M5 Datasheet
حجم فایل 821.638 کیلوبایت
نوع فایل pdf
تعداد صفحات 11

دانلود دیتاشیت HSP053-4M5 Datasheet

HSP053-4M5 Datasheet Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: HSP
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Type: Steering (Rail to Rail)
  • Unidirectional Channels: 4
  • Voltage - Reverse Standoff (Typ): 5V (Max)
  • Voltage - Breakdown (Min): 5.3V
  • Voltage - Clamping (Max) @ Ipp: -
  • Current - Peak Pulse (10/1000µs): -
  • Power - Peak Pulse: -
  • Power Line Protection: Yes
  • Applications: HDMI, USB
  • Capacitance @ Frequency: 0.35pF @ 200MHz ~ 2.5GHz
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 5-XFDFN
  • Supplier Device Package: 5-uQFN (1.3x0.8)
  • Base Part Number: HSP053
  • detail: Clamp Ipp Tvs Diode Surface Mount 5-uQFN (1.3x0.8)
