TPS71710DCKR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TPS71710DCKR |
|---|---|
| حجم فایل | 99.144 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 45 |
دانلود دیتاشیت TPS71710DCKR |
دانلود دیتاشیت |
|---|
سایر مستندات
TPS717xx Datasheet 45 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TPS71710DCKR
- Output Type: Fixed
- Output Current: 150mA
- Output Voltage: 1V
- Dropout Voltage: 300mV@(150mA)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 6.5V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 80uA
- Power Supply Rejection Ratio (PSRR): 70dB@(100Hz,1kHz),45dB@(1MHz)
- Package: SC-70-5
- Manufacturer: Texas Instruments
- Current - Supply (Max): 100µA
- Output Configuration: Positive
- Package / Case: 5-TSSOP, SC-70-5, SOT-353
- Packaging: Cut Tape (CT)
- Protection Features: Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
- Number of Regulators: 1
- Part Status: Active
- Current - Quiescent (Iq): 80µA
- Supplier Device Package: SC-70-5
- Voltage - Input (Max): 6.5V
- Voltage - Output (Min/Fixed): 1V
- Mounting Type: Surface Mount
- PSRR: 70dB ~ 45dB (100Hz ~ 1MHz)
- Base Part Number: TPS717
- Series: -
- Control Features: Enable
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.3V @ 150mA
- Current - Output: 150mA
- detail: Linear Voltage Regulator IC 1 Output 150mA SC-70-5
