- Datasheet ST662AB/C
ST662ABD-TRY Datasheet
Datasheet specifications
| Datasheet's name | ST662AB/C |
|---|---|
| File size | 871.111 KB |
| File type | |
| Number of pages | 20 |
Download Datasheet ST662AB/C |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: STMicroelectronics
- Series: Automotive, AEC-Q100
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- Function: Step-Up
- Output Configuration: Positive
- Topology: Charge Pump
- Output Type: Fixed
- Number of Outputs: 1
- Voltage - Input (Min): 4.5V
- Voltage - Input (Max): 5.5V
- Voltage - Output (Min/Fixed): 12V
- Voltage - Output (Max): -
- Current - Output: 30mA
- Frequency - Switching: 400kHz
- Synchronous Rectifier: No
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SO
- Base Part Number: ST662
- detail: Charge Pump Switching Regulator IC Positive Fixed 12V 1 Output 30mA 8-SOIC (0.154", 3.90mm Width)
