دیتاشیت EMIF02-MIC03M6
مشخصات دیتاشیت
| نام دیتاشیت |
EMIF02-MIC03M6
|
| حجم فایل |
332.706
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
11
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
EMIF
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
Low Pass
-
Filter Order:
2nd
-
Technology:
RC (Pi)
-
Number of Channels:
2
-
Center / Cutoff Frequency:
-
-
Attenuation Value:
-
-
Resistance - Channel (Ohms):
68
-
Values:
R = 68Ohms, C = 45pF
-
ESD Protection:
Yes
-
Operating Temperature:
-40°C ~ 85°C
-
Applications:
Data Lines for Mobile Devices
-
Voltage - Rated:
-
-
Mounting Type:
Surface Mount
-
Package / Case:
6-UFDFN
-
Size / Dimension:
0.057" L x 0.039" W (1.45mm x 1.00mm)
-
Height:
0.026" (0.65mm)
-
Base Part Number:
EMIF02
-
detail:
RC (Pi) EMI Filter 2nd Order Low Pass 2 Channel R = 68Ohms, C = 45pF 6-UFDFN
