دیتاشیت ESDA8V2-1MX2
مشخصات دیتاشیت
| نام دیتاشیت |
ESDA8V2-1MX2
|
| حجم فایل |
253.208
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
10
|
مشخصات
-
Manufacturer:
STMicroelectronics
-
Series:
ESDA, TRANSIL™
-
Packaging:
Cut Tape (CT)
-
Part Status:
Obsolete
-
Type:
Zener
-
Unidirectional Channels:
1
-
Voltage - Reverse Standoff (Typ):
5V
-
Voltage - Breakdown (Min):
8.2V
-
Voltage - Clamping (Max) @ Ipp:
18.5V
-
Current - Peak Pulse (10/1000µs):
27A (8/20µs)
-
Power - Peak Pulse:
500W
-
Power Line Protection:
No
-
Applications:
General Purpose
-
Capacitance @ Frequency:
350pF @ 1MHz
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
2-UFDFN
-
Supplier Device Package:
2-µQFN (1.45x1.0)
-
Base Part Number:
ESDA8
-
detail:
18.5V Clamp 27A (8/20µs) Ipp Tvs Diode Surface Mount 2-µQFN (1.45x1.0)
